Product Parameter:

①　One side of the camera is marked with a yellow chart and the other is an infrared camera.

②　The power consumption of the whole machine is about 24W and the weight is about 30kg

③　Operating temperature -25 to 60 degrees

④　Working voltage of single head (excluding camera) : DC12V

⑤　Single head (excluding camera) operating current: 1A

⑥　Maximum current of single head (excluding camera) : 1.6A

⑦　Machine operating current: 2A

⑧　Maximum rotation Angle of equipment: 360 degrees horizontal / 180 degrees vertical

⑨　Equipment protection level: IP68 explosion-proof level: Exd ⅡCT6 / DIP A20 TA, T6

⑩　Support video output: Onvif/http/rtsp output

Technical Parameter:

1. Noise equivalent temperature difference (NETD) is 50mk and below

2. Operating temperature -40 to 60 degrees

3. Thermal imaging focal length: 35mm/50mm/75mm (optional)

4. Focusing mode: fixed focus

5. Detector detection type; Uncooled focal plane microbolometer

6. Thermal imaging detector resolution: 384x288/640X480 optional

7. Pixel spacing: ≤17μm, response band: 7μm-14μm

8. Thermal imaging black heat, white heat, iron red, rainbow and other at least 7 kinds of false color mode optional

9. Video output: Digital video

10. The equipment supports infrared monitoring with gigabit Ethernet output, dynamic temperature measurement function

11. The movement adopts NBT patented technology without blind vision and baffle structure to achieve continuous screen monitoring without interruption.

12. The movement USES TIE digital image details to enhance the patented technology, the picture is more delicate and clear

13. Customize start up logo screen

14. Full screen custom OSD overlay

15. Overvoltage undervoltage protection function, reverse connection protection function:

16. Built-in fire risk temperature warning module;

17. Support thermal imaging video area intrusion detection, entry area detection and exit area detection

18. Support isotherm function and alarm function for temperature anomalies. Alarm can be carried out if the preset temperature is exceeded in the thermal imaging detection temperature area

19. Supports the automatic protection function of infrared thermal imager and has the function of strong light detection and infrared sensor shielding
