Product name:
Low temperature infrared monochromatic temperature measuring system
Product model:
LM-DS0130
Product name:
Low temperature infrared monochromatic temperature measuring system
Product model:
LM-DS0130
Temperature measuring Probe
The infrared temperature sensor can calculate the surface temperature of the object by measuring the infrared radiation intensity emitted by the target without contacting the target. Non-contact temperature measurement is the biggest advantage of infrared temperature sensor, which enables users to easily measure targets that are difficult to approach or move.
The infrared temperature sensor is an integrated infrared temperature measurement device. The sensor, optical system and electronic circuit are integrated in the stainless steel case. Easy to install, the standard thread on the metal shell can be quickly connected to the installation part; At the same time, there are various types of options (such as blower, mounting bracket, adjustable mounting bracket, purge protection sleeve, etc.) to meet the requirements of various working conditions.
Technical parameters of infrared temperature probe
Protection grade: IP65
Environment temperature:0-60℃
Storage temperature: -20℃-80℃
Relative humidity:10-95%
Material: Stainless steel
Cable length:2m(standard), other size customized
Working power:24VDC/3.3VDC/12VDC
Max current:50MA
Output signal: 4-20MA linear /0-5V linear
Spectral region:8-14μm
Measured temperature accuracy: measured value ±1 or 1℃, take big value
Repeatability:measured value ±0.5% or ±1℃,take big value.
