Product name:
Infrared two-color temperature measuring system
Product model:
LM-ST3512
Product name:
Infrared two-color temperature measuring system
Product model:
LM-ST3512
Product introduction:
1. Wide range of temperature measurement, 350℃ ~ 1200℃
2. High measurement accuracy, ±0.5% FS
3. Large distance coefficient, up to 400:1(100:1)
4. Small target measurement, can accurately measure the minimum 2mm target temperature
5. Fast response, up to 20ms
6. Instantaneous value, maximum value and average value are three ways of temperature measurement
7. 4MA ~ 20MA output, can be directly connected with standard digital display table, LED large-screen display, PLC, etc
8. Isolated RS485 digital output can form a network in which up to 32 temperature measuring instruments can be accessed to provide communication protocol and demonstration Software, facilitate the customer's secondary development
9. High brightness LED display, suitable for industrial field use
10. Coaxial laser aiming, easy to use, high accuracy
11. Telescopic sight aiming, clear and direct
Technical parameters:Analog output: A：0V～5V B：4MA～20MA
Temperature measuring parameters:
1. Temperature measurement range: 350℃ ~ 1200℃
2. Measurement accuracy: ±0.5% FS
3. Repeat accuracy: ±0.3% FS or ±1℃
4. Response time: ≤ 50ms, maximum resolution up to 20ms:
5. display temperature resolution 0.1℃
6. RS485 output temperature resolution 1℃
7. The current output temperature resolution is 0.1℃
8. Shooting rate: adjustable from 0.10 ~ 1.00, step size: 0.01
9.Temperature measurement: instantaneous value (TEM), maximum value (MAX), average value (AVG)
10. Time interval: 1 ~ 30 seconds step length 1 second
Optical parameters:
1. Operating band: 2.6μm
2. Aiming method: Coaxial laser aiming or telescope aiming
3. Range coefficient: 400:1 (100:1)
4. power:24V DC ±10%，100MA
5. Signal output: Analog current output: 4MA ~ 20MA
6. RS485 digital output: Baud rate: 9600, 1 starting bit, 8 data bit, no odd-digit parity, 1 stop bit
7. Working temperature: -10℃ ~ 60℃; Use air cooling up to 100℃;
8. Use water cooling up to 150℃;
9. Storage temperature up to 200℃ : -20 ℃ ~ 80℃
10. Protection level: IP65
11. Weight:0.5KG
12. Dimension: Diameter 50mm，length 167mm
